Spindle gauge(mm) |
220 |
Spindle number |
4 |
Package dimension(mm) |
φ150×400 |
Bobbin dimension (mm) |
φ45×445 |
Drafting system |
Four rollers double short apron drafting |
Drafing multiple |
2.00-30.00 |
Twist range (T/M |
Continuously adjustable |
Length for fibre |
22 - 51mm( Four roller) |
(Tex) De nsity for yam |
200-1250 |
Pressing form |
Pendulum spring pressing、Pneumatic weight Arm、Leaf spring Pressing |
Bottom roller digmeterimm |
Φ28.5,φ28.5,φ28.5,φ28.5 |
Top roller diameter(mm) |
Φ28.8,φ28.8,φ25,φ28.8 |
Cleaning device |
Positive revolving belt |
Max Mechanical speed(R/M) |
1600 |
Transmission device |
Seven frequency inverter motor |
Control type |
Computerized Automatic control |
Man-machine interaction |
Touch screen |
Winding transmission |
Gear transmission |
Flyer transmission |
Gear transmission |
Winding power shaft |
Frequency inversion direct driving |
Yarn forming angle |
Software |
Three auto doffing |
Software |
Signal display |
Five Lamps Indicated On Machine Headstock |
Tension adjustment |
Software |
Tension fine adjustmenl |
Software |
Unevenness preventing |
Software |
Sliver faults preventing |
Software |
Winding density adjustment |
Software |
Twist changing |
Software |
(mm) Can diameter |
φ400,φ500 |
(kw) Main Motor power |
(Winding motor)1.5kw flyer motor)1.5kw (One、Two,three and four roller motors)0.75kw (lifting motor)0.75kw |
{ db(A)}Noise standard |
<85 |
4s(mm) Overall dimension |
1800×1000(2000) |
4s (t) Weight |
1.8 |
